POLY-NORM AZR torsionally flexible, fail-safe standard drop-out center design coupling
KTR POLY NORM AZR
KTR-GERMANY
According to manufacturer standards
0985.288.164
HOTLINE TƯ VẤN : 0985.288.164
Applications of our torsionally flexible, fail-safe shaft coupling with brake drum (drum brake):
• POLY-NORM AZR with standard drop-out center design parts for bridging large shaft distances. The coupling allows for replacing the elastomer without dismounting driving or driven components. The standard application range is the pump industry.
• Applications with minor specifications can be combined with POLY-NORM GJL hubs.
Operation of fail-safe shaft coupling:
• The POLY-NORM shaft coupling consists of two hubs half the cams of which are each inserted in the tailor-made free spaces of the other hub.
• This compact design of the shaft coupling allows to connect the shafts with a particularly short shaft distance dimension. The elastomer positioned between the cams transmits the torques while compensating for any kind of displacement.
Variation of components of fail-safe shaft coupling:
• High adaptability with low variance through an optimally differentiated construction kit system: The elements within one size of POLY-NORM® shaft coupling can easily be combined with each other. This allows to realize various shaft distances with the same basic component.
Size parameter KTR POLY NORM AZR:
CATALOGUE THE COUPLING KTR POLY NORM AZR
